MTI  |  SKU: MSKESPS60

60kV max. High Voltage Power Supply for DIY Electrospinning - MSK-ESPS-60KV

€0,00

Delivery and Shipping to EU

We will add in the quotation, the shipping, insurance, customs clearance costs.

60kV max. High Voltage Power Supply for DIY Electrospinning - MSK-ESPS-60KV

MTI

 MSK-ESPS-60-24V is an AC input DC output high voltage power supply designed for the DIY Electrospinning device.

High voltage power in the system must have Grounding tests(GFCI) before first-time use. Improper grounding may cause charge build-up and damage the unit.

SPECIFICATIONS



Features
  • Digital Voltmeter and Current display
  • Output voltage and current can be set by using knobs on the front panel and read from the digital display
  • Constant current/Constant Voltage mode of operation
  • Built-in Arc Protection Circuit
    Input Power

  • 208 - 240V AC (50/60Hz)
  • 150W Max power consumption
  • You may order a 200W transformer to run it at 110VAC
  • Power Inlet and Outlet Cable are included
Output Power
 DC 0 - 60 kV Single Output, 2.5 mA max Current
Dimensions

 214mmL×285mmW×67mmH
Operational Environment Temperature:    0 - 50 °C
Humidity:         10 - 80% RH
Compliance NRTL certification is available upon request at the extra cost
Warranty One-year limited warranty with lifetime support
Options
  • You may need Syringe Pump to deliver liquid, Please click the Pic. 1 below to order.
  • You may need a drum collector to make coating ( Please click Pic. 2 to order)
  • You may order X-Y stage for flat coating, please click Pic. 3 right to order
  • Please put the device into a fume hood for safety and health  ( Pic. 4)
  • DIY an Ultrasonic Spray and Electrospinning device
  •        Pic. 1     Pic. 2   Pic. 3   Pic. 4
Operation Instructions
