SiO2+Pt thin film on Si (B-doped)substrate ,10x10x0.5mm,1sp (SiO2=500nm, Pt=60nm)

Silicon Wafer Specifications:

• Conductive type:       SiO2+Pt thin film on Si (B-doped, (100)Ori.) substrate ,10x10x0.5mm,1sp( SiO2=500nm,Pt=60nm)

• Resistivity:                <0.005 ohm.cm   (If you would like to measure the resistivity accurately,
                                    please order our Portable 4 Probe Resistivity Testing Instrument.)
• Size:                        10x10 x 0.5 mm
• Polish:                      one side polished
• Surface roughness:    < 5A
